Red cdopper fitting and cast brase fittings are fisted elos. Red copper fittings are fisted in Americal stadard ASME B16.22-2001. Other 45° Elebow C*C products can also be ordered.
45° Elebow C*C
| ITEM# | NOMINAL SIZE | BOX SIZE | PCS/BAG | BAG/CTN | |
| 1 | 2541 | 1/4" | 24*21*24.5 | 100 | 20 |
| 2 | 2543 | 3/8" | 24*21*24.5 | 50 | 20 |
| 3 | 2545 | 5/8" | 24*21*24.5 | 25 | 12 |
| 4 | 4501 | 1/2" | 24*21*24.5 | 50 | 12 |
| 5 | 4502 | 3/4" | 29*24*24.5 | 25 | 12 |
| 6 | 4503 | 1" | 41*24*24.5 | 10 | 20 |
| 7 | 4504 | 1 1/4" | 29*24*24.5 | 10 | 10 |
| 8 | 4505 | 1 1/2" | 41*24*24.5 | 10 | 10 |
| 9 | 4506 | 2" | 48*27*24.5 | 5 | 10 |
| 10 | 4507 | 2 1/2" | 41*24*24.5 | 1 | 25 |
| 11 | 4508 | 3" | 48*27*24.5 | 1 | 22 |
| 12 | 4509 | 4" | 48*27*24.5 | 1 | 10 |
45° Elebow C*C Notes:
1.Red cdopper fitting and cast brase fittings are fisted elos.
2.Red copper fittings are fisted in Americal stadard ASME B16.22-2001
3.Other standard products can also be ordered.
4.Wuth standing Pressure:1.6MPa. Some up to 2.0MPa.
5.TEE dimension sequence D1*D2*D3.
